Name: INS 60V22Ah Lithium-Ion Battery Pack 1+1-Year Warranty
SKU: 6317
Availability: InStock

The INS 60V 22Ah NMC Lithium-Ion Battery Pack is a high-performance power source designed for e-scooters, e-bikes, and custom EV applications. Built with premium NMC lithium cells and a smart BMS, this battery offers excellent power output, long cycle life, and safe, reliable performance.
With an efficient energy capacity and optimized discharge capability, the battery delivers a real-world mileage of 55–60 km per charge, depending on riding conditions, motor power, and load.
Lightweight yet powerful, this battery is ideal for users seeking improved performance, longer range, and reduced charging time compared to traditional lead-acid batteries.

Key Features:

High-Performance 60V NMC Lithium Battery Pack
Real-world mileage: 55–60 km per charge
BMS Protection (Overcharge, Over-discharge, Overcurrent, Short-circuit)
Long Cycle Life – up to 1200 cycles
Fast Charging Support (6A Standard, up to 10A Maximum)
Stable power output for better pickup, torque & overall performance
Lightweight and compact design compared to lead-acid batteries
Suitable for e-scooters, e-bikes, and 60V EV conversion kits
1+1 Year Warranty (1 Year Full + 1 Year Service Warranty)

What’s Included:

1× INS 60V 25Ah Lithium-Ion Battery Pack

1× Anderson Connectorer

Warranty Card

Field	Description
Model Number	INS-60V-22Ah-NMC
Battery Type	Li-ion (NMC)
Nominal Voltage (V)	60V
Nominal Capacity (Ah)	22Ah
Energy (Wh)	1320Wh
Dimensions (L × W × H)	200 × 160 × 160 mm
Weight (kg)	8.650 kg
Cycle Life	Up to 1200 cycles
Max Continuous Discharge Current (A)	10A
Peak Discharge Current (A)	30A
Charge Voltage (V)	67.2V
Standard Charge Current (A)	6A
Max Charge Current (A)	10A
BMS Protection	Overcharge, Over-discharge, Overcurrent, Short-circuit
Operating Temperature	15°C to 45°C
Storage Temperature	0°C to 45°C
Connector Type	Anderson
Warranty	1+1 Year (Full + Service)
Applications	E-Scooter, E-Bike, EV Conversion Kits

Weight	8.65 kg
Dimensions	20 × 16 × 16 cm

1-Year Standard Warranty on battery Pack
1-Year Free Service Warranty

What Covered under Warranty: Manufacturing Defects, Cell Performance Issues, BMS Malfunction. Charging/Discharging Faults, Connector & Wiring Failures, Unexpected Shutdown / Performance Failure.

What Not Covered under Warranty: Physical Damage, Water Damage Improper Installation, Overcharging / Over-Discharging, External Short Circuit, Tampering or Unauthorized Repairs, Burnt/Fire Damage, Swollen or Damaged Cells Due to Misuse, Use in Non-Recommended Applications,Deep Discharging.
