JBD Smart BMS 10–14S 40A (Bluetooth/ UART )

₹1,699.00

Add to Wishlist
Add to Wishlist

The JBD 10–14S Smart BMS is a high-quality Battery Management System designed for Lithium-Ion / NMC/LFP battery packs ranging from 10S to 14S.
It provides advanced protection, accurate cell monitoring, and smart communication support, ensuring safe, stable, and long-lasting battery performance.

This smart BMS supports Bluetooth / UART communication (model dependent), allowing users to monitor cell voltage, total voltage, current, temperature, SOC, and protection status in real time through a mobile app.

Ideal for E-bikes, E-scooters, solar energy storage systems, EV battery packs, and custom lithium battery builds.

Key Features

  • Supports 10S to 14S Lithium-Ion / NMC/LFP  battery packs
  • Smart BMS with real-time monitoring (Bluetooth/UART support)
  • Passive cell balancing for longer battery life
  • Full protection: overcharge, over-discharge, overcurrent, short-circuit
  • Temperature protection with NTC sensor support
  • Accurate voltage & current sensing
  • Compact design, easy installation
  • Suitable for EV, ESS, and DIY lithium battery packs

What’s Included

  • 1 × JBD 24S 40A Smart BMS
  • All necessary wiring harness
  • 14S balance wire
Category Specification
Model JBD Smart BMS 10-14S 40A
Battery Type Lithium-ion / NMC/LFP
Supported Series (S) 10s-14S
Nominal Voltage Range 24V / 36V / 48V (depending on S count)
Max Voltage Up to 58.8V (14S @ 4.2V per cell)
Continuous Discharge Current 40A
Charging Current 40A
Communication Bluetooth / UART
Balancing Type Passive Balancing
Balance Current 50–60mA
Overcharge Protection Yes
Over-Discharge Protection Yes
Over-Current Protection Yes
Short-Circuit Protection Yes
Temperature Protection Yes (NTC sensors supported)
Port Type Common Port
Quiescent Current ≤60µA
Operating Temperature –20°C to +75°C
Dimensions Approx. 130 × 60 × 15–22 mm
Weight Approx. 120g
Applications EV, E-scooter, E-bike, solar energy storage, ESS, custom lithium packs
Weight .3 kg
Dimensions 10 × 7 × 1 cm

No Warranty Provided

This product does not come with any warranty.
Each BMS is individually checked and tested by our technical team before dispatch to ensure proper working condition. We ship only after confirming the product is functional and free from visible defects.

Important Notes

  • No replacement or refund after the product is delivered.
  • Buyer must ensure correct wiring and installation.
  • We are not responsible for damage caused by wrong connection, overcurrent, short-circuit, or misuse.

Quality Assurance

Even though there is no warranty, we follow strict testing procedures:

  • Function test
  • Balance circuit test
  • MOSFET output check
  • Voltage & protection check

Product is shipped only after confirming everything is working.
